Description
U.S. Army Technical Manual TM 9-1240-348-34P for M25 Telescope Mount, March 1971
Item Overview
This original U.S. Army technical manual is the direct-support and general-support maintenance repair-parts reference for the M25 Telescope Mount. Issued as TM 9-1240-348-34P in March 1971, it helped maintenance and supply personnel identify and order components for this field-artillery sight mount. This listing is for the technical manual only. It does not include an M25 mount, panoramic telescope, howitzer, or other fire-control equipment.
Identification and Features
The “34P” suffix identifies this as a direct-support and general-support repair-parts and special-tools publication. It includes depot-maintenance repair parts where required and focuses on illustrated parts identification rather than complete operating or repair procedures.
- Manual number: TM 9-1240-348-34P
- Publication date: March 1971
- Subject: M25 Telescope Mount
- Former development designation: T29
- Official item name: Mount, Telescope
- Part number: 7578429
- Federal Stock Number: 1240-757-8429
- Manual type: Repair parts and special tools list
- Maintenance levels: Direct support and general support
- Supported telescopes: M12A7C and M12A7G Panoramic Telescopes
- Primary weapon application: M1A1 and M1A2 155mm Howitzers, later designated M114-series
- Primary sighting role: Indirect fire
- Issuing authority: Headquarters, Department of the Army
- Country of origin: United States
- Item included: Technical manual only
Manual Coverage
This publication supports parts identification, ordering, and higher-level maintenance of the M25 mount. Manuals of this type normally contain exploded illustrations, item numbers, official part names, stock and manufacturer numbers, quantities, supply codes, maintenance codes, and special-tool information. It is useful for identifying loose parts and determining where they belong in the complete mount assembly.
How the M25 Mount Worked
The M25 held and supported an M12A7C or M12A7G Panoramic Telescope on the howitzer carriage. Its leveling and adjustment mechanisms allowed the optical instrument to be properly aligned with the weapon. The gunner used the panoramic telescope to set direction and deflection for indirect fire against targets that could not be seen from the gun position.
Weapon-System Application
The M25 was part of the fire-control equipment used on the M1A1 and M1A2 155mm Howitzers, which were later redesignated as members of the M114 series. The mount provided a stable connection between the carriage and panoramic telescope. This allowed the crew to aim from firing data supplied by the fire-direction center while the separate elevation and quadrant equipment controlled the angle of the cannon tube.
Historical Background
The M114 family began as the 155mm Howitzer M1, which entered production during World War II. Improved versions were designated M1A1 and M2 before the weapon became the M114 under the Army’s 1962 designation system. The howitzer provided medium-artillery fire support with greater range and shell weight than standard 105mm weapons. The M25 mount came from the same World War II-era fire-control system and remained supported as long as these howitzers stayed in service.
History of Use
M114-series howitzers served with American forces during World War II, the Korean War, and the Vietnam War. They were used for high-explosive, smoke, illumination, and other indirect-fire missions. The weapon also served with many allied countries and remained in use after newer U.S. artillery systems began replacing it. This March 1971 manual reflects continued Army support for the M25 mount during the later service life of the M114 family.
Condition
Please check the pictures for the general condition of the item. This listing is for one TM 9-1240-348-34P technical manual only; the M25 mount, M12A7-series panoramic telescope, M114-series howitzer, and other equipment are not included.
Ideal For
This specialized publication is useful for collectors, restorers, museums, and researchers studying U.S. field-artillery optics and the M114-series 155mm howitzer.
- U.S. Army technical-manual collections
- M25 telescope-mount restoration
- M12A7 panoramic-telescope research
- M114 155mm howitzer displays
- World War II artillery collections
- Korean War and Vietnam War exhibits
- Military fire-control equipment research
- Museum and archival collections
Approx length 8", Approx width 11", Approx height .2", Approx weight .2lbs.
Pictures are stock images of our inventory. Unless otherwise noted, you will not be receiving the exact item shown in the pictures. The pictures are representative of the item’s general condition. The item you receive might be slightly better, or worse, condition than was shown in the pictures.
