Technical Manual (TM 9-1240-298-34P) for M34, M34A1, M34A2, and M34A2C Sight Units July 1972 FSN 1240-759-7854
U.S. Army Technical Manual TM 9-1240-298-34P for M34, M34A1, M34A2, and M34A2C Sight Units, July 1972
Item Overview
This U.S. Army technical manual is a repair-parts and special-tools reference for the M34, M34A1, M34A2, and M34A2C Sight Units. Issued as TM 9-1240-298-34P in July 1972, it supported personnel responsible for maintaining optical fire-control equipment used with mortars, recoilless rifles, and rocket launchers.
This listing is for the technical manual only. It does not include an M34-series sight unit, telescope mount, elbow telescope, weapon, tools, or replacement parts.
About the M34-Series Sight Units
The M34 family was a portable fire-control system used to aim several types of crew-served weapons. The basic sight assembly combined optical, mounting, leveling, and angle-setting components.
A typical system included the M79 Telescope Mount, M9 Telescope Adapter, and M62 Elbow Telescope. The M79 provided elevation settings, cross-level adjustment, and a longitudinal level. An M42 Instrument Light could illuminate the sight for nighttime use.
Different M34 versions were matched to specific weapons and mounting arrangements. The sight unit was separate from the mortar, recoilless rifle, or rocket launcher on which it was installed.
Documented Weapon Applications
The M34-series sight units served with a wide range of U.S. weapons:
- M34 and M34A1: M30 4.2-inch Mortar and M27/M27A1 105mm Recoilless Rifle
- M34A2: M29 81mm Mortar, M84 4.2-inch Self-Propelled Mortar, M21 4.5-inch Multiple Rocket Launcher, and M20 75mm Recoilless Rifle
- M34A2C: XM34 318mm Rocket Launcher
These applications gave the M34 series a connection to infantry, artillery, chemical-mortar, armored-vehicle, and rocket units.
Historical Background
The M34 family was developed during the early Cold War as the Army expanded and improved its portable fire-control equipment. Its applications ranged from manually carried recoilless rifles to heavy mortars and vehicle-mounted weapon systems.
Several associated weapons had roots in World War II or the Korean War, while later M34 versions remained in use during the Vietnam era. The M34A2 was also used with the M84 self-propelled mortar, which placed the M30 4.2-inch mortar on a tracked armored chassis.
By 1972, the Army needed one current parts publication covering four related sight configurations. This manual records the shared components and differences needed to maintain the complete M34 family.
Publication Details
- Manual number: TM 9-1240-298-34P
- Publication date: July 1972
- Subjects: M34, M34A1, M34A2, and M34A2C Sight Units
- Manual type: Direct-support and general-support repair parts and special tools list
- Additional coverage: Depot-maintenance repair parts and special tools
- Associated telescope mount: M79
- Associated telescope adapter: M9
- Associated elbow telescope: M62
- Associated instrument light: M42
- Item included: Technical manual only
Models, Stock Numbers, and Part Numbers
- M34 Sight Unit: FSN 1240-759-7854; P/N 7597854
- M34A1 Sight Unit: FSN 1240-764-7931; P/N 7647931
- M34A2 Sight Unit: FSN 1240-300-7989; P/N 8244840
- M34A2C Sight Unit: FSN 1240-783-5932; P/N 7674715
Collector and Research Value
This manual is a useful addition to a U.S. Army technical-publication, mortar, recoilless-rifle, rocket-artillery, or military-optics collection. Its illustrations and parts data can assist with sight identification, restoration research, and museum displays.
The wide range of documented weapon applications also makes it a valuable reference for studying the development of U.S. fire-control equipment from the early Cold War through the Vietnam era.
Ideal For
- U.S. Army technical-manual collections
- M34-series sight-unit identification
- Mortar and recoilless-rifle restoration research
- Cold War and Vietnam War displays
- Military-optics and fire-control collections
- Museum and archival collections
Approx length 8", Approx width 10", Approx height .15", Approx weight .2lbs.
