Special Purpose Cable Assembly for 20mm Vulcan on F-4 Phantom
$2,650.00
In stock
SKU
Special Purpose Cable Assembly for 20mm Vulcan on F-4 Phantom
Toggle Nav
The #1 Online Source for Military Museum Displays • Movie Props • Training Aids • Historical Artifacts
NSN: 1005-00-906-0806 / 6150-00-906-0806
Genuine U.S. Military Surplus | Aircraft Armament Electrical Connector Assembly
This is a Special Purpose Cable Assembly designed for use with the 20mm M61 Vulcan rotary cannon as installed on the legendary McDonnell Douglas F-4 Phantom II. This original U.S. military component is classified under NSN 1005-00-906-0806 and NSN 6150-00-906-0806, indicating its dual role as both an armament system part and an electrical cable harness.
This assembly is new old stock (NOS) and was purpose-built to support the Vulcan's high-speed electrical firing and ammunition handling functions within the F-4's internal or podded gun system. Its robust construction is engineered to withstand the intense vibration, temperature, and electrical loads associated with high-rate aerial cannons.
Historical Context – The F-4 Phantom & M61 Vulcan Integration
The F-4 Phantom II, introduced in the late 1950s, became one of the most iconic multi-role fighters of the Cold War, serving across all major branches of the U.S. military and dozens of allied air forces worldwide. As air combat doctrine evolved during the Vietnam War, the necessity for internal guns became clear. This led to the M61A1 Vulcan being installed internally on later F-4E models and externally via SUU-16/A or SUU-23/A gun pods on earlier variants.
The Special Purpose Cable Assembly was a mission-critical link between the aircraft's electrical fire control system and the M61A1 cannon, ensuring safe, synchronized operation. Its role was vital to the function of the 6-barrel 20mm Vulcan, which was capable of firing at rates exceeding 6,000 rounds per minute.
Product Details:
- Item: Special Purpose Cable Assembly
- Application: Electrical interface for 20mm M61 Vulcan on F-4 Phantom
- NSN: 1005-00-906-0806 / 6150-00-906-0806
- Condition: New Old Stock
- Compatibility: F-4E Phantom (internal gun); F-4C/D via SUU-series Vulcan gun pods
- Use: Connects fire control system to gun subsystem
Ideal For:
- Collectors of Cold War U.S. aircraft armament systems
- F-4 Phantom restoration projects
- Aviation museums and display builds
- Aerospace engineering educators and ordnance trainers
- Historic aircraft weapons tech preservationists
This is a rare opportunity to acquire a genuine electrical assembly once used in one of the most iconic aircraft weapon systems of the 20th century. Whether you're restoring an F-4 system, assembling a display, or preserving aviation history, this component is a must-have.
Approx length 46", Approx width 1.5", Approx height 1.5", Approx weight 1lbs.
Pictures are stock images of our inventory. Unless otherwise noted, you will not be receiving the exact item shown in the pictures. The pictures are representative of the item's general condition. The item you receive might be slightly better, or worse, condition than was shown in the pictures.
Please visit our page about order lead times here: Order Lead Times
