Inert Mk 15 Mod 6 Snakeye Bomb Fin Assembly, NSN 1325-01-213-9659

Item Overview

This inert Mk 15 Mod 6 fin assembly belongs to the Snakeye retarding-tail family used with the 500-pound Mk 82 general-purpose bomb. The design used folding fins to increase air resistance and slow the bomb during its descent, giving the releasing aircraft more time to clear the target area.

Identification and Features

The item is identified by the supplied designation FIN BOMB MK 15 MOD 6 and NSN 1325-01-213-9659. The Mk 15 design provided a streamlined configuration with its fins closed and a high-drag configuration with its fins deployed. Navy F/A-18 documentation also lists the Mod 6 with the BDU-45/B practice bomb and Mk 62 Quickstrike mine.

  • Item type: Bomb fin assembly
  • Designation: Mk 15 Mod 6
  • Fin family: Snakeye
  • NSN: 1325-01-213-9659
  • Primary bomb application: 500-pound Mk 82 general-purpose bomb
  • Design function: Aerodynamic retardation
  • Additional marking as supplied: F7G8 NUWC DET KPT HAW DET 8/11
  • Status: Inert

Historical Background

The Snakeye fin family formed part of U.S. efforts to adapt general-purpose aircraft bombs for low-altitude delivery. Official Navy photographs document Mk 82 Snakeye bombs in combat over Vietnam in 1965, including use by F-4B Phantom II aircraft operating from USS Midway. The Mk 15 family remained covered in the Navy’s 2001 Aviation Ordnanceman training manual. This history describes the fin family rather than the service history of this individual Mod 6 assembly.

Condition

This is an inert bomb fin assembly. Please check the pictures for the general condition of the item.

Ideal For

This assembly is suited to collections and educational displays covering aircraft ordnance and retarding-fin development.

  • Mk 82 Snakeye bomb displays
  • U.S. Navy aviation ordnance collections
  • Aircraft bomb-fin research
  • Military museum and educational exhibits

Approx length 36", Approx width 18", Approx height 18", Approx weight 65lbs.

Pictures are stock images of our inventory. Unless otherwise noted, you will not be receiving the exact item shown in the pictures. The pictures are representative of the item’s general condition. The item you receive might be slightly better, or worse, condition than was shown in the pictures.
