5" / 127mm Mark 32 Mod 0 Anti-Tank Anti Personnel with Mark 71 Mod 1 Rocket Motor
$4,500.00
In stock
SKU
5" / 127mm Mark 32 Mod 0 Anti-Tank Anti Personnel
Toggle Nav
The #1 Online Source for Military Museum Displays • Movie Props • Training Aids • Historical Artifacts
Put a true Cold War heavy hitter on display with this restored 5" / 127mm Mark 32 Mod 0 Anti-Tank Anti Personnel with Mark 71 Mod 1 Rocket Motor. This is a full-length, inert representation of the classic 5-inch Zuni ATAP rocket, finished with a CNC-machined aluminum replica fuze that completes the correct nose profile for museum-grade presentation.
The 5" Zuni – Heavyweight Folding-Fin / WAFAR Rocket
5" / 127mm Mark 32 Mod 0 Anti-Tank Anti Personnel with Mark 71 Mod 1 Rocket Motor, Developed in the 1950s as a modular system: one motor, multiple warheads, and a range of fuzes for different missions. It was carried mainly in four-round pods and cleared for both air-to-air and air-to-ground use, but in practice became a workhorse strike and close air support rocket in U.S. Navy and Marine Corps service, especially during the Vietnam War.
Later-production Zunis used the Mk 71 rocket motor, which introduced a smokeless propellant and a new wrap-around fin nozzle assembly. This wrap-around fin arrangement led to the Mk 71 family often being referred to as WAFAR (Wrap-Around Fin Aerial Rocket) rather than the earlier FFAR (Folding-Fin Aircraft Rocket) terminology.
Zuni ATAP rockets like this Mk 32 / Mk 71 combination were used against light armor, vehicles, bunkers, gun positions, and troop concentrations, making them one of the most versatile heavy rockets in the U.S.
Mark 32 Mod 0 ATAP Warhead – HEAT / Fragmentation
The 5.0-inch Rocket Warhead Mark 32 Mod 0 is the dedicated Anti-Tank Anti-Personnel (ATAP) head for the Zuni system. It is a HEAT-FRAG design, combining a shaped charge with a controlled-fragmentation steel shell so a single warhead can defeat both armored and soft targets.
Typical live-service characteristics:
- Type: ATAP (Anti-Tank Anti-Personnel), HEAT-FRAG
- Warhead weight: about 45.7 lb
- Explosive filler: approx. 15 lb Composition B
- Fragmentation effect:
-
- Produces over 2,000 quarter-inch steel fragments
- Capable of damaging light vehicles and personnel out to roughly 70 ft (about 21 m)
- Armor penetration (with point-detonating fuze):
-
- Up to 18 in (457 mm) of armor at 0°
- Around 7 in (178 mm) at 65° obliquity
Paired with appropriate impact or proximity fuzes, the Mk 32 Mod 0 was equally at home punching through armor or shredding area targets with fragmentation, which is why it appears in documentation under the ATAP designation.
Mark 71 Mod 1 WAFAR Rocket Motor
The Mk 71 Mod 1 is the high-performance Zuni rocket motor that replaced the earlier Mk 16 series. It uses a smokeless solid propellant and a redesigned nozzle/fin section with wrap-around fins, improving accuracy and handling while reducing launch signature.
Typical data for the Mk 71 Mod 1 motor (live configuration):
- Motor-only mass: about 79.5 lb (36 kg)
- Diameter: 5 in (127 mm)
- Length: roughly 77–82 in, depending on specific Mod and configuration
- Thrust: approx. 8,100 lbf for about 1.8 seconds
When fitted with the Mk 32 ATAP warhead, the result is a fast, heavy, and extremely destructive rocket well-suited for close air support, anti-armor strikes, and hard-target attack.
About This Specific Restored Round
- Original 5" Mark 32 Mod 0 ATAP Warhead – Professionally Restored
-
- Constructed from a genuine Mk 32 Mod 0 ATAP warhead body, correctly painted and refinished.
- Restored to show the proper HEAT-FRAG ATAP configuration, including correct external body form and banding.
- Mated to a Mark 71 Mod 1 WAFAR Rocket Motor (Inert)
-
- Warhead is assembled to an authentic Mk 71 Mod 1 rocket motor body, giving the full-length Zuni silhouette.
- Motor is completely inert: no propellant, no igniter, no energetic components remain.
- CNC-Machined Aluminum Replica Fuze
-
- A precision CNC-machined aluminum fuze replicates the shape and proportions of the operational nose fuze used on ATAP Zunis.
- Entirely inert, but visually completes the rocket, which is critical for aircraft pylon, LAU-10 pod, or ground rack displays.
- Fully Inert & Safe for Display
-
- No explosive filler in the warhead
- No live fuze parts
- No propellant or initiators in the motor
- Sold strictly as an inert, non-functional display item
This rocket is for static display only. It cannot be fired and must not be modified in any attempt to restore live function.
Ideal For
- Vietnam-era and Cold War aircraft displays (A-4, A-7, F-4, F-8, OV-10, and similar platforms)
- Museum exhibits on naval aviation, close air support, and rocket / HEAT technology.
- Advanced ordnance collections focused on anti-tank rockets, ATAP warheads, and U.S. 5" rocket evolution.
- Shop, hangar, or office displays where a large, visually impressive rocket becomes an instant focal point
Approx length ", Approx width ", Approx height ", Approx weight lbs.
Pictures are stock images of our inventory. Unless otherwise noted, you will not be receiving the exact item shown in the pictures. The pictures are representative of the item's general condition. The item you receive might be slightly better, or worse, condition than was shown in the pictures.
