2.75" / 70mm Mark 5 High Explosive Anti-Tank Rocket with Mark 40 Mod 3 Motor
$1,975.00
In stock
SKU
2.75" / 70mm Mark 5 High Explosive Anti-Tank Rocket-1
Toggle Nav
The #1 Online Source for Military Museum Displays • Movie Props • Training Aids • Historical Artifacts
Add a true early-generation anti-armor aircraft rocket to your collection with this restored 2.75" / 70mm Mark 5 High Explosive Anti-Tank (HEAT) rocket, correctly assembled on an original Mark 40 Mod 3 Folding-Fin Aerial Rocket (FFAR) motor. This full-length rocket captures the form, proportions, and hardware of an operational Mk 5 HEAT rocket while remaining completely inert and safe for static display.
The Mark 5 warhead retains its original internal shaped-charge / EFP (visible in the photos), giving you a rare opportunity to show the real internal geometry of a HEAT warhead without any explosive components.
The Mark 5 HEAT Warhead
The Mk 5 HEAT warhead was one of the earliest shaped-charge heads fielded on the U.S. 2.75" Folding-Fin Aerial Rocket (FFAR)—the famous “Mighty Mouse.” Developed in the 1950s, it provided fighters and, later, attack helicopters with a compact, air-launched anti-tank and anti-armor weapon.
Key reference characteristics for the live Mk 5 HEAT warhead:
- Type: High Explosive Anti-Tank (HEAT) shaped-charge warhead
- Filler (live configuration): Approx. 404 g (14.2 oz) of Composition B main charge plus a tetryl booster behind a copper shaped-charge
- Effect: Forms a focused, high-velocity jet capable of perforating armor and hardened point targets
- Service use: Employed on fixed-wing aircraft and rotary-wing platforms from the early Cold War into the Vietnam era, typically loaded in 7- and 19-tube pods under wings and pylons
The Mk 5 HEAT round represents the “10-pounder-class” anti-tank warhead in the 2.75" family—a direct ancestor of later HEAT and dual-purpose warheads developed for the Hydra 70 system.
Your warhead preserves the original EFP (explosively formed penetrator) inside the body, while inert.
Mark 40 Mod 3 Folding-Fin Rocket Motor
The Mk 40 was the universal follow-on motor developed from the original Mk 4 2.75" FFAR. It introduced a more powerful motor and nozzle changes optimized for slow-speed platforms and armed helicopters, and could be fitted with a wide variety of warheads—HE, HEAT, flechette, smoke, illumination, and more.
The Mk 40 Mod 3 variant is a standard operational configuration, distinguished mainly by its internal igniter and bulkhead layout. In service, rockets with Mk 40 Mod 3 motors were widely used from aircraft and helicopter pods such as the LAU-3, LAU-32, M158, and M159.
Typical live Mk 40 rocket characteristics (with HE-type warheads) include:
- Caliber: 2.75 in / 70 mm
- Motor role: Solid-fuel folding-fin rocket motor, spin-stabilized
- Use: Air-to-surface and, historically, some air-to-air applications from a wide range of U.S. fixed- and rotary-wing aircraft
Paired with the Mk 5 HEAT warhead, the Mk 40 Mod 3 motor gives you a correct, full-length early FFAR anti-tank rocket suitable for Vietnam-era and Cold War aircraft and helicopter displays.
About This Restored Mk 5 HEAT Rocket (Warhead + Mk 40 Mod 3 Motor)
Authentic Mk 5 HEAT Warhead with Original Liner
- Built from a genuine U.S. 2.75" / 70mm Mk 5 HEAT warhead body, not a reproduction.
- Retains the original shaped-charge EFP inside the warhead, providing a true representation of how the live warhead was constructed.
Original Mk 40 Mod 3 Rocket Motor (Inert)
- Genuine Mk 40 Mod 3 FFAR rocket motor casing, restored for display.
- Correct folding-fin tail section and overall length give the rocket its classic full-length FFAR profile when mated to the Mk 5 warhead.
- Motor is inert: no propellant grain, no igniter, no live components present.
Display-Ready Exterior Finish
- Warhead and motor are restored in a service-appropriate scheme, with period-style markings where applicable.
- Ready to mount under a wing, alongside a pod, on a wall display, or in a museum case as a complete Mk 5 HEAT / Mk 40 Mod 3 rocket.
NSN / NIIN / DODIC Reference (Live-Service Mk 5 HEAT Warheads)
For collectors and researchers, U.S. CAPULDI ammunition data associate the Mk 5 HE warhead with the following identifiers (live items):
- DODIC / DODAC H837 – Warhead, 2.75 inch, HE Mk 5
- NSN 1340-00-038-8176 – WARHEAD, 2.75 INCH, HE MK5
-
- NIIN 000388176CAPULDI 2009
Ideal For
- Vietnam-era and early Cold War aircraft armament displays featuring 2.75" FFAR pods
- Helicopter gunship collections (UH-1, AH-1, and similar) needing a correct 2.75" Mk 5 HEAT rocket for pod or pylon loadouts
- Museums and training programs explaining HEAT warhead construction andCAPULDI 2009apons
- Advanced ordnance collections comparing early FFAR HEAT rockets to later Hydra 70 HE, HEAT, and HEDP rounds
Approx length 50", Approx width 2.75", Approx height 2.75", Approx weight 15lbs.
Pictures are stock images of our inventory. Unless otherwise noted, you will not be receiving the exact item shown in the pictures. The pictures are representative of the item's general condition. The item you receive might be slightly better, or worse, condition than was shown in the pictures.
Please visit our page about order lead times here: Order Lead Times
