2.75" / 70mm Mark 5 High Explosive Anti-Tank Rocket with Mark 4 Mod 10 Motor
$1,995.00
In stock
SKU
2.75" / 70mm Mark 5 High Explosive Anti-Tank Rocket
Toggle Nav
The #1 Online Source for Military Museum Displays • Movie Props • Training Aids • Historical Artifacts
Bring a classic early-generation anti-armor aerial rocket back to life on your wall, pod, or pylon display with this restored 2.75" / 70mm Mark 5 High Explosive Anti-Tank (HEAT) rocket mated to an original Mark 4 Mod 10 Folding-Fin Aerial Rocket (FFAR) motor. This piece captures the look and proportions of an early “Mighty Mouse”-era HEAT rocket while remaining completely inert and safe for static display.
The Mark 5 HEAT Warhead
The 2.75" FFAR family was developed in the late 1940s–1950s as a lightweight, modular rocket system for U.S. fighters and attack aircraft, originally fielded as the “Mighty Mouse” air-to-air rocket and later adapted for air-to-ground work. Among its early warheads was the Mark 5 HEAT head, designed to penetrate armor and hard targets using a shaped charge rather than pure blast/fragmentation.
Key historical characteristics of the live Mk 5 HEAT warhead (for reference):
- Type: High-Explosive Anti-Tank (HEAT) shaped-charge warhead
- Filler: Approximately 404 g (about 14.2 oz) of Composition B explosive behind a shaped-charge cone
- Effect: Focused armor-piercing jet intended for use against armored vehicles and hardened point targets
- Platform use: Carried on fixed-wing aircraft and, later, rotary-wing platforms using 7- and 19-tube launch pods in the FFAR family
Your warhead retains the original Explosively Formed Penetrator (EFP) (visible in the photos), preserving the correct internal geometry of the warhead cavity while remaining inert.
Mark 4 Mod 10 Folding-Fin Rocket Motor
The Mark 4 rocket motor is the classic 2.75" FFAR “Mighty Mouse” motor, an unguided, solid-fuel rocket body with folding tail fins that deploy at launch for stabilization. The Mod 10 variant was produced under U.S. military specification MIL-R-60995 for operational service, and later served as one of the standard motors for a wide variety of 2.75" warheads.
Typical characteristics for the Mk 4 motor (for reference with an HE warhead):
- Diameter: 2.75 in / 70 mm
- Motor length (approx.): 99.8 cm (39.3 in)
- Motor weight (approx.): 5.0 kg (11 lb), depending on warhead
- Propulsion: Solid-fuel rocket, folding tail fins, spin-stabilized
On display aircraft and in ordnance collections, a Mk 4 motor with a HEAT head like the Mk 5 represents the early generation of U.S. 70mm rockets that eventually evolved into the later Mk 40
and Hydra 70 / Mk 66 family.
About This Restored Mk 5 HEAT Rocket (Rocket + Motor)
- Authentic Components, Professionally Restored
-
- Built from a genuine 2.75" Mark 5 HEAT warhead body fitted to an original Mark 4 Mod 10 FFAR motor.
- Original EFP/shaped-charge liner retained in the warhead for maximum authenticity, while all explosive filler and energetic components are removed.
- Correct Visual Profile
-
- Restored exterior with the proper HEAT ogive and body profile unique to the Mk 5 warhead, giving a noticeably different silhouette than later blast/fragmentation heads.
- Mark 4 Mod 10 motor restored with the classic FFAR body and four-fin tail section, matching period photos and technical references.
- Display-Ready Finish
-
- Finished in an appropriate service-style scheme suitable for aviation displays.
- Markings and stenciling replicate operational 2.75" HEAT rocket markings for an “on-the-flight-line” look.
Completely Inert, Non-Functional Assembly
- The Motor is inert.
- Warhead is inert.
- Retained EFP is strictly a metal component with no energetic material present.
- No part of this item is intended for reactivation, modification for firing, or any functional use. It is sold strictly as an inert display and educational collectible.
NSN / NIIN / DODIC Reference (Live-Service Mk 5 HEAT Warheads)
For researchers and serious collectors, CAPULDI unitization data lists the live 2.75" FFAR Mk 5 HEAT warhead under DODIC H837 with several NSNs.
Examples include (for historical reference only):
- DODIC: H837 – Warhead, 2.75 Inch Rocket HEAT FFAR Mk 5
- NSN: 1340-00-038-8176 (NIIN 000388176) – Mk 5 HEAT warhead, various pack configurations
- Additional NSNs associated with H837 Mk 5 HEAT warheads include 1340-00-309-5068 and 1340-00-309-5098 for different packaging data sets
Ideal For
- Completing Vietnam-era and early Cold War aircraft stores displays
- LAU-3 / M158 / M159-style rocket pod and pylon setups on jets and attack helicopters
- Museum collections focusing on the evolution of 2.75" FFAR and early air-launched anti-armor weapons
- Advanced ordnance collections where a correct Mk 5 HEAT rocket with original liner and Mk 4 motor is a centerpiece
Approx length 50", Approx width 2.75", Approx height 2.75", Approx weight 15lbs.
